PRODUCTS
Paper Napkin Machine (Single-Size)
Our Automatic Paper Napkin Machine is designed to quickly and efficiently fold jumbo rolls into square or rectangular paper napkins. With its advanced system, this machine can handle printing, embossing, counting, and folding with ease.
Thanks to its variable frequency drive, the speed of the automatic paper napkin folder can be easily controlled to match the requirements of your production line. Plus, the counting function can be easily adjusted to ensure that you’re producing the right number of napkins every time.
For added convenience, we’ve included an extra remote control on the back side of the machine. This allows operators to adjust the machine’s speed while feeding paper at the beginning, ensuring that the process is smooth and efficient from start to finish.
Product Details
Main Feature
- Single Deck.
- Embossing Unit having metal to paper ball type in either full or border pattern
- Electronic Counting for absolute accuracy
- The separation between stacks is with the single napkin lift which is operated pneumatically
- Integrated bandsaw to cut One lane into two stacks on the delivery deck
- Heavy machine structure
- Blade sharpening
- Air Shaft for Jumbo Paper Roll
- Gear Box
- Machine controls at both ends
- All branded electronics are used
Options
- Pneumatic Lift for Jumbo Paper Roll
- Web Guide
- Static Eliminator
- Mechanical Shaft for Jumbo Paper Roll
Additional information
| Working Width | 400mm~270mm (As Per Requirement) |
|---|---|
| Printing Unit | As Per Requirement |
| Embossing Unit | As Per Requirement |
| Parent Roll Diameter | 1200mm |
| Parent Roll Core Inner Diameter | 76mm |
| Raw Paper Material | 1~3 Layer Tissue Paper (18-36g/m2) |
| Unwind Unit | One or more (As per Requirement) |
| Folding Size | 1/4 |
| Speed | 300 to 600 sheets per minute (speed varies according to quality of paper, sheet size and printing area) |
| Installed Power | 440v A.C., 50Hz, 2.2kW |
| Air Pressure Required | 5 P.S.I. |
| Transmission | Timing Belts |
| Speed Regulations | Variable Frequency Drive |
| Weight | 2000~2500kgs |
| Space Required | 16' x 4' x 6' |
